Description
HFS-H hydraulic flange spreaders provide the ideal solution for safely opening pipe flanges in the marine and oil & gas industry. Available in capacities from 0 – 4.5 tonnes and 0 – 10 tonnes, these models offer the user the capability of opening flanges up to 2 x 57 mm or 2 x 92 mm thick respectively. Hi-Force flange spreaders can be operated individually, or as a pair when opening large flanges using a standard pump and connecting hose.
- Capacities from 4.5 to 10 tonnes
- Quick and easy to assemble on flange
- Working pressure 700 bar
- Single acting, spring assisted return cylinder for fast and safe operation
- Suitable for fitment onto flanges with a maximum stud bolt size of 1 5/8″ (41 mm)
- Spreading range from 61 to 224 mm
- Lightweight ergonomic design for ease of use
