HAS Range

Description

The HAS range of single acting, lightweight, aluminium cylinders is specifically designed for applications where weight and ease of positioning are features of prime importance. With an average weight of approximately 50% of comparable capacity steel construction cylinders, all models are supplied with a hard anodised, wear resistant, piston rod and cylinder body and a steel cylinder base protection plate. Available lifting capacities range from 32 to 110 tonnes capacity, at maximum working pressure of 700 bar. All models are commonly used in a wide variety of industrial applications in shipyards, steel mills, construction and power plants. Other capacities and stroke length options available on request.

• Capacities from 32 to 110 tonnes
• Stroke lengths from 51 to 305 mm
• Working pressure 700 bar
• Spring assisted return
• Hard anodised piston rod and cylinder
• Steel base plate to protect cylinder body
• Low friction bearing surfaces
• Optional piston rod saddles
• Customised and special design cylinders are available on request
