Digital Gauge

Description

The Hi-Force HDG1 digital pressure gauge is capable of measuring hydraulic pressure up to 1000 bar (14,503 psi) and can display in a variety of units of measure that include bar, psi, mPa, kg/cm², as well as one additional user defined, programmable unit. This high quality gauge offers an accuracy of 0.5% across its full scale range and incorporates a laser welded, stainless steel sensor & socket making it suitable for use with a wide variety of fluids. Standard features also include tare, min and max memory, blue backlight display, rubber protective enclosure and IP65 weatherproof enclosure rating.

• 5 digit LCD display
• Choice of pressure readings
• 0.5% full scale accuracy

• LCD display with 12 mm, 5 digit upper line pressure reading and 6 mm, 5 digit lower line unit reading.
• Blue backlight allows reading in low visibility situations
• 20 segment graphical display of pressure
• Minimum 2000 hours battery life (3 VDC)
• Supplied with protective rubber enclosure
• Suitable gauge mounting blocks available
