Description
The HVL pancake cylinder range combines a very low closed height with a 6mm stroke, providing a precise adjusting and lifting force in very confined work areas. Ideally suited for applications requiring alignment of machinery, turbines, heavy structures etc. All models are single acting, load return design. The base of all HVL cylinders must be fully supported during use.
- Capacities from 10 to 104 tonnes
- Stroke length 6 mm
- Working pressure 700 bar
- Single acting load return
- Nitrocarburised piston rod
- Low friction bearing surfaces
- Anti-extrusion seals
- Customised and special design cylinders are available on request
