Description
The HGG range of load return industrial cylinders is specifically designed for lifting and maintenance applications. All models are supplied with a tilting saddle to reduce the risk of damage caused by side loading and an integral stop ring for stroke limitation is fitted as standard. Standard range models are featured here however additional capacities and stroke options are available on request.
- Capacities from 152 to 326 tonnes
- Stroke length 155 mm
- Working pressure 700 bar
- Single acting, load return
- Nitrocarburised piston rod
- Integral stop ring for piston stroke limitation
- Tilting saddle fitted as standard
- Low friction bearing surfaces
- Anti-extrusion seals
- Customised and special design cylinders are available on request
