HPF Range

Description

The HPF hydraulic workshop presses are designed and manufactured, with maximum strength and durability, to provide years of safe and trouble-free operation. Ideally suited for use in workshop maintenance applications, the range offers capacities from 10 to 200 tonnes with stroke lengths up to 330 mm, operating at maximum pressures of 700 bar.

The HPF press models feature a robust steel frame construction and incorporate an adjustable work table with additional adjustable top bed on all models 50 tonnes capacity and above. All models are supplied with dual scale, hydraulic pressure gauge for increased safety and load monitoring. Factory fitted optional accessories include multi-positional V-blocks with flat bed and V-shape press surfaces.

• Capacities from 10 to 200 tonnes
• Stroke lengths from 250 to 330 mm
• Working pressure 700 bar

• Strong steel frame construction
• Easily adjustable work table on all models
• Adjustable upper bed on all models 50 tonnes and above
