HTWP Range

Description

Hi-Force HTWP hydraulic torque wrench pumps are compatible for use with all Hi-Force hydraulic torque wrenches. All models are 700 bar maximum working pressure, fitted with an easily accessible and adjustable torque setting pressure relief valve, and are available as air driven or electric driven pump units. All pumps are supplied with a remote operation, push button hand pendant controller with 3 metres of control line cable. Glycerine filled, easy to read, dual scale (0-700 bar/0-10,000 psi) hydraulic pressure gauges are fitted as standard to all models. Air driven versions also include an integral inline filter, regulator, lubricator system with airline pressure gauge and an exhaust air cooling system.

• Working pressure 700 bar
• Two stage operation
• Air or electric driven options

• 110, 120, 220 and 230 volt single phase electric motor with auto retract function
• Integral oil cooling system in air driven models
• Externally adjustable torque setting valve
• Reservoir oil sight level gauge
• Air pressure gauge and filter-regulator-lubricator unit on air driven models
• Oil reservoir capacity 5 litres
• Factory fitted roll bar protection frame included
