TWH-N Range

Description

Hi-Force TWH-N series female hexagon cassette head hydraulic torque wrenches offer a choice of 5 models with output torque capacities from 2625 Nm to 48181 Nm (1906 to 34985 lbf.ft). Manufactured from high grade aluminium (except TWH430N), all models provide direct in-line reaction and a minimal radius clearance for easy fitment in confined spaces. The user friendly design of the tool simply requires the operator to withdraw/insert a single pin to change the ratchet head. Ratchet heads are available in all standard metric and imperial AF sizes from 24 to 175 mm (1 1/16” to 6 7/8”) with low cost hexagon reducer bushes also available.

All models except the TWH430N are fitted with a multi-directional 360° x 360° swivel. TWH430N is fitted with a multi-directional 360° x 180° swivel. Both swivels are fitted with quick release couplings, and the multi-directional features enable easy positioning of hydraulic hoses during operation, preventing damage from pinching or kinking.

• Torque capacities up to 48181 Nm
• Torque accuracy of +/- 3%
• Working pressure 700 bar

• Compact, lightweight, aluminium drive unit (except TWH430N)
• Low profile design for limited access applications
• Easily assembled to the selected ratchet head
• Minimum radius cassette head for fitment in confined spaces
• Suitable for continuous operation at maximum pressure
